IOy Series integrates centralized control for AV, HVAC, and lighting systems, improving efficiency, reducing energy consumption, and enhancing room management at the international convention center.

Case Details

The international convention center has 15 multi-function halls (ranging from 80–500 m² each) and required:
1.Centralized control of AV equipment (projectors, matrix switchers, conference systems, etc.) in each hall
2.Intelligent management of environmental devices (HVAC, lighting, motorized curtains)
3.Interconnected control between subsystems
4.Status monitoring of all multi-function halls from a central control room

Hardware Configuration

Device Type	Model	Quantity	Function
Main Controller	IOy	15 units	Main control unit for each hall
Digital I/O Module	16DI16DO	30 units	Discrete control
Analog I/O Module	8AI8AO	15 units	Environmental parameter acquisition
Communication Gateway	BL100 Series	15 units	Protocol conversion

Implementation Details

1. AV Equipment Control
IOy RS232 port connects to Crestron AV control system
Modbus RTU protocol controls Extron matrix switchers
Integrated control of Bose digital audio processors

2. Environmental Control
Lighting Control: BL203 DO channels control relays for zone dimming
HVAC Control: BL201 collects temp/humidity data and communicates with McQuay HVAC units via BACnet
Curtain Control: DO signals control Somfy motorized curtain drives

3. Automated Scenes

Technical Highlights
Multi-Protocol Support:Beilai gateway enables seamless integration of RS232/485, TCP/IP, BACnet, Modbus, etc.Ensures compatibility with multi-brand devices

Reliable Communication:Beilai's proprietary BusLink technology,Baud rate: 115.2 kbps, Bit error rate: <0.001%

Precision Control:Analog input accuracy: ±0.1%,Discrete I/O response time: <10 ms

Performance Results
Key Metrics:Mean Time Between Failures (MTBF): >10,000 hours,Command response time: <200 ms,Data acquisition refresh rate: 1 second

Client Benefits:
35% decrease in equipment failure rate
28% reduction in energy consumption
50% improvement in room turnover efficiency
