Infrastructure Monitoring (BTS, pumping stations, tanks, buildings, river/flood control);
Energy & Environmental Management (oil/gas pipelines, substations, weather stations, streetlight control);
Security & Alarm Systems (surveillance, unmanned machine rooms, leakage detection, corrosion protection);
Equipment & Machinery Control (valves, transformers, vending machines, boats/vehicles);
Data Acquisition & Automation (temperature/humidity, liquid levels, wellheads, M2M communication).
|
Item |
Reference Scope |
|
DC Power supply |
Standard adapter: DC 12V/2A Range 9-36VDC |
|
Power consumption |
Standby:12V/130mA; Working Max.: 12V/500mA |
|
TCP/IP stack |
TCP,UDP |
|
Serial Interfaces |
1 USB Port |
|
Protocols |
SMS, GPRS UDP,TCP,MQTT, Modbus RTU, Modbus TCP and more equipment protocols can be added according to requirements. |
|
Ethernet |
1 RJ45 Ethernet port for connect internet. |
|
RS485 |
2 RS485, Support Transparent transmission and Modbus RTU Slave, Modbus RTU Master. |
|
Digital Inputs |
8 Digital input, NC/NO type,wet /dry contact .DIN0 can be used as high speed pulse counter max 1MHz,DIN1-3 can be used as low speed pulse counter max 1KHz.DIN1 can arm and disarm. |
|
Analog Inputs |
6 Analog Inputs. 24 bit resolution, 0-5V or 0-20mA or 4-20mA; |
|
Temp.&Hum Inputs |
Temperature range: -40°C to +80°C, Humidity Range: 0~100%RH; |
|
Relay Outputs |
4, Rated: 5A/30VDC,5A/250VAC |
|
Power Outputs |
1 Port, for external device; |
|
Extend I/O tags |
Max.320 |
|
Memory Capacity |
Internal 32G SD card inside, can save the data for 100000events. |
|
Backup Battery |
3.7V 850mAH(Not included by default. Please specify when ordering if needed) |
|
Temperature range |
-20°C ~ +70 °C |
|
Humidity range |
Relative humidity 95% (condensation free) |
|
Exterior dimension |
70mm*87mm*52mm |
|
Net Weight |
350g |
|
Model |
GSM/3G/4G |
Ethernet |
DIN |
AIN/ PT100 |
Relay |
T&H |
SD Card |
Mapping Registers |
||||
|
Boolean |
16-Bit |
32-Bit |
64-Bit |
RS485 Port |
||||||||
|
S475 |
√ |
√ |
8 |
6 |
4 |
1 |
32G |
64 |
128 |
64 |
64 |
2 |
|
S475E |
× |
√ |
8 |
6 |
4 |
1 |
32G |
64 |
128 |
64 |
64 |
2 |
|
Notice |
1. Default version is GSM/GPRS module inside. 2. Please check the slave devices’ register quantity and data type,then choose the right model of S475/S475E according to the mapping registers in the model list. 3. For 3G WCDMA, 4G LTE version, please tell our sales where would you like to use them. 4. The S475E series has no communication module, so it can't call and SMS to alarm. |
|||||||||||
Note: The package does not include any SIM card.
