GSM Frequency: |
Quad-band 850/900/1800/1900 MHz (Both 3G/4G ready) |
|
Wireless Zones: |
95 |
|
Radio Frequency: |
433.92MHz for sensors, 315MHz for wireless switch (*optional) |
|
Wired Zones: |
2, NC/NO dry contact |
|
Tamper Switch Zone: |
1, at back side of panel |
|
Digital Output: |
1 relay, NC/NO dry contacts, 3A/240VAC, 5A/24VDC |
|
Max. Stored Phone No.: |
9 phone numbers for alarm SMS & call |
|
Max. Remote Control: |
9 pcs |
|
Event Logs: |
999 alarm logs, 99 operation logs |
|
Internal Audible Alarm: |
95dB |
|
CMS: |
KingCenter CMS-01, or Contact ID CMS Supported (GPRS data) |
|
Rated Power Supply: |
9~24V DC/1A |
|
Power Consumption: |
12V input Max. 270mA, Standby 30mA |
|
SIM Card: |
Support 3V SIM Card |
|
Antenna: |
50 Ω SMA Antenna interface |
|
Temperature Range: |
-20~+60 °C |
|
Humidity Range: |
Relative humidity 90% (condensing free) |
|
Backup Battery: |
3.7V /900 mAH Li-ion rechargeable |
|
Enclosure Material: |
ABS plastic |
|
Exterior Dimension: |
18.8*13.1*2.8 cm (7.4*5.1*1.1 inch) |
|
Net Weight: |
320 g (0.7 lb) |
