IOy Series Model Selection
|
NO. |
Name |
Model |
Uplink protocol |
|
1 |
Modbus TCP Edge I/O Module |
BL190 |
Modbus TCP |
|
2 |
OPC UA Edge I/O Module |
BL191 |
OPC UA |
|
3 |
MQTT Edge I/O Module |
BL192 |
MQTT |
|
4 |
Versatile Edge I/O Module |
BL192Pro |
MQTT, Modbus TCP, OPC UA |
|
5 |
SNMP Edge I/O Module |
BL193 |
SNMP |
|
6 |
BACnet/IP Edge I/O Module |
BA190 |
BACnet/IP |
|
7 |
Building HVAC Edge I/O Module |
BA190Pro |
BACnet/IP, MQTT, Modbus TCP, OPC UA |
|
8 |
IEC104 Edge I/O Module |
BE190 |
IEC104 |
|
9 |
Energy and Photovoltaic Edge I/O Module |
BE190Pro |
IEC104, MQTT, Modbus TCP, OPC UA |
|
10 |
Profinet I/O Module |
BL196 |
Profinet |
|
11 |
EtherCAT I/O Module |
BL197 |
EtherCAT |
|
12 |
Ethernet/IP I/O Module |
BL198 |
Ethernet/IP |
Y Series I/O Module Selection
|
NO. |
Name |
Model |
Channel |
Signal Type |
|
1 |
8CH Digital Input Module |
Y11 |
8 |
NPN(Low-Level Triggering) |
|
2 |
8CH Digital Input Module |
Y12 |
8 |
PNP(High-Level Triggering) |
|
3 |
8CH Digital Input Module |
Y13 |
8 |
Dry Contact |
|
4 |
8CH Digital Output Module |
Y21 |
8 |
PNP |
|
5 |
8CH Digital Output Module |
Y22 |
8 |
NPN |
|
6 |
8CH Digital Mixed Module |
Y01 |
8 |
4DI+4DO NPN |
|
7 |
8CH Digital Mixed Module |
Y02 |
8 |
4DI+4DO PNP |
|
8 |
4CH Analog Input Module |
Y31 |
4 |
0-20mA/4-20mA |
|
9 |
4CH Analog Input Module |
Y33 |
4 |
0-5V/0-10V Single-Ended Input |
|
10 |
4CH Analog Input Module |
Y34 |
4 |
0-5V/0-10V Differential Input |
|
11 |
4CH Analog Input Module |
Y36 |
4 |
±5V/±10V Differential Input |
|
12 |
4CH IEPE Measurement Module |
Y37 |
4 |
Low-Impedance Voltage Signal Output (e.g., for acquiring acceleration, pressure, decibel data) |
|
13 |
4CH Analog Output Module |
Y41 |
4 |
0-20mA/4-20mA |
|
14 |
4CH Analog Output Module |
Y43 |
4 |
0-5V/0-10V |
|
15 |
4CH Analog Output Module |
Y46 |
4 |
±5V/±10V |
|
16 |
2CH RTD Input Module |
Y51 |
2 |
3-Wire PT100 |
|
17 |
2CH RTD Input Module |
Y52 |
2 |
3-Wire PT1000 |
|
18 |
2CH RTD Input Module |
Y53 |
2 |
4-Wire PT100 |
|
19 |
2CH RTD Input Module |
Y54 |
2 |
4-Wire PT1000 |
|
20 |
4CH TC Input Module |
Y58 |
4 |
TC(B/E/J/K/N/R/S/T) |
|
21 |
8CH Pulse Output and Pulse Counting Module |
Y95 |
8 |
4CH Pulse Output + 4CH Pulse Counting (NPN) |
|
22 |
8CH Pulse Output and Pulse Counting Module |
Y96 |
8 |
4CH Pulse Output + 4CH Pulse Counting (PNP) |
|
23 |
4CH Serial Port Module |
Y61 |
4 |
4*RS485/RS232 optional |
|
24 |
4CH Serial Port Module |
Y62 |
4 |
1*CAN+3*RS485/RS232 reserve |
